Magnesium V3
$99.00 USD
Description
Magnesium is the Product Of The Year SoundStage! Network!
The Mg IEM utilizes a high magnesium content alloy (96% Mg) for the diaphragm material. Magnesium is the least dense of all stable metals. Magnesium is also very high on the stiffness-to-weight ratio, and that is why it’s used in automotive and aerospace applications. These two properties result in a highly efficient, low distortion transducer foundation.
All components inside our IEMs was 100% designed and tooled in-house, resulting a totally unique product. Each component was designed to do its function, be as light weight as possible, and easy to assemble. All components are keyed so that assembly is nearly fool-proof. All components were finite-element analyzed for stress, strain, and durability.
The sonic signature of the Mg IEM is relatively neutral but with a brighter top end than our Be unit. Many people prefer this sound for use in noisier environments. Ideal genres are blues, jazz, and acoustic/folk.
All our IEMs feature Eastman Tritan™ bodies for high strength and zero resonance, custom front-and-rear tuned volumes, Metal-Injected-Molded grade 304 stainless steel logo caps, butyl rubber strain reliefs, chemically etched grade 316 stainless steel grilles, and N48H grade magnets. And bonded together and sealed in precision alignment with cyanoacrylate and polyvinyl acetate adhesives.
Every IEM set comes with a full set of accessories. We manufacture our own earbuds from medical grade silicones and urethanes, and we include small, medium, and large sizes of single flange, dual flange and foam units. We stamp our own screw-top carry tin sized to fit inside the coin pocket of a pair of your favorite jeans. And you’ll get adapters that let you use your IEMs with any equipment, whether at home (the 1/4″ gold plated adapter jack) or on the go (the lightweight, gold plated airplane adapter).
Still not sure that this IEM is for you? Then use our amazing Select-A-Tron to guide your IEM choice!
Specifications
| Performance | |
|---|---|
| Frequency Response | 20 Hz to 30 kHz |
| Impedance | 32 Ohms nominal |
| Sensitivity | 101 dB SPL at 1mW in ear |
| Power Handling | 200 mW continuous |
| Peak SPL | 121 dB |
| THD | Less than 1.5% THD at 1mW |
| Physical Properties | |
|---|---|
| Cable Length | 1.5 m |
| Mass | 2.8 / 9.3 g (IEM/Set) |
| Operational Temperature | -20 to +50° C |
| Operational Humidity | 0-95% Relative Humidity |
| NRR | 31.3 dB (foam eartrip) |
| Overall Length | 21 mm |
| Body Diameter | 12 mm |
| Nozzle Diameter | 6 mm |
| Material Properties | |
|---|---|
| Melting Point | 922 Kelvin |
| Speed of Sound | 4940 meters per second |
| Young’s Modulus | 45 Gigapascals |
| Brinell Hardness | 260 Megapascals |
Additional information
| Weight | 1 kg |
|---|
Description
Magnesium is the Product Of The Year SoundStage! Network!
The Mg IEM utilizes a high magnesium content alloy (96% Mg) for the diaphragm material. Magnesium is the least dense of all stable metals. Magnesium is also very high on the stiffness-to-weight ratio, and that is why it’s used in automotive and aerospace applications. These two properties result in a highly efficient, low distortion transducer foundation.
All components inside our IEMs was 100% designed and tooled in-house, resulting a totally unique product. Each component was designed to do its function, be as light weight as possible, and easy to assemble. All components are keyed so that assembly is nearly fool-proof. All components were finite-element analyzed for stress, strain, and durability.
The sonic signature of the Mg IEM is relatively neutral but with a brighter top end than our Be unit. Many people prefer this sound for use in noisier environments. Ideal genres are blues, jazz, and acoustic/folk.
All our IEMs feature Eastman Tritan™ bodies for high strength and zero resonance, custom front-and-rear tuned volumes, Metal-Injected-Molded grade 304 stainless steel logo caps, butyl rubber strain reliefs, chemically etched grade 316 stainless steel grilles, and N48H grade magnets. And bonded together and sealed in precision alignment with cyanoacrylate and polyvinyl acetate adhesives.
Every IEM set comes with a full set of accessories. We manufacture our own earbuds from medical grade silicones and urethanes, and we include small, medium, and large sizes of single flange, dual flange and foam units. We stamp our own screw-top carry tin sized to fit inside the coin pocket of a pair of your favorite jeans. And you’ll get adapters that let you use your IEMs with any equipment, whether at home (the 1/4″ gold plated adapter jack) or on the go (the lightweight, gold plated airplane adapter).
Still not sure that this IEM is for you? Then use our amazing Select-A-Tron to guide your IEM choice!
Nerd Layer
I See a Detachable Cable? What’s That About?
We have also developed our own 2.5mm jack: the IDEEL connector. This connector is the world’s smallest 2.5mm jack, measuring just 3.6mm across, and a tiny 9.5mm mounting depth. This jack allows us to use the very robust 2.5mm TS plug in our tiny IEMs. No more delicate MMCX or difficult 2 pin plastic connectors needed.
Mechanical Elements
Transducer Diaphragm: 96% pure Magnesium foil
Transducer Surround: PEEK polymer
Transducer Frame: 316 Stainless Steel
Transducer Magnet: N48H Grade Neodymium
Enclosure Body: Tritan™ copolyester
Protective Grille: 316 Stainless Steel
Bonding Compound: Cyanoacrylate Adhesive
Sealant Compound: Polyvinyl Acetate
Mounting Tips: Medical Grade Silicone and Urethanes
Connector: IDEEL 2.5mm TS compatible connector (tip hot, sleeve ground)
All components are Finite Element Analyzed for stress, strain, and durability.
Performance Specifications
Frequency Response: 20 Hz to 30 kHz
Impedance: 32 Ohms nominal
Sensitivity: 101 dB SPL at 1mW in ear
Power Handling: 200 mW continuous
Peak SPL: 124 dB
THD: Less than 1.5% THD at 1mW
Included Components
Included Components
- Ti IEMs
- 1.2 meter long cable single 3.5mm TRS to dual 2.5mm TS jack and metal shells
- Carrying Case
- Single Flange Tips – Small, Medium, Large
- Dual Flange Tips – Small, Medium, Large
- Memory Foam Tips – Small, Medium, Large
- Protective Travel Case
- Gold Plated ¼” TRS Adapter Jack
- Gold Plated Dual Mono Airplane Adapter
Physical Specifications
Cable Length: 1.2 m
Mass: 2.8 / 16.7 g (each IEM/Set)
Operational Temperature: -20 to +50° C
Operational Humidity: 0-95% Relative Humidity
NRR: 31.3 dB (foam eartrip)
Overall Length: 21 mm
Body Diameter: 12 mm
Nozzle Diameter: 6 mm
