Sale!
ID: 1742
PERIODIC AUDIO

Titanium V3

(1 customer review)

$129.00 USD

SKU: 855033007201 Categories: , ,

Description

Titanium is just plain fun. In your face. Kick in the pants. Boogie down or bang the head. Ti does it all. Unabashedly not accurate. This isn’t your 3 piece jazz ensemble IEM. This is a full-on, blast your face rock concert. It’s a thunderous EDM club. It’s reggae all day long. Ti just makes you move. Ultra-light weight in your ears, super-flexible cable, and robust polycarbonate construction makes sure you’ll never focus on Ti, just the jams rolling through your ears. Enough sensitivity and flat impedance to make your cellphone sound as powerful as a PA rig, but tough enough to take what a big-power amp like our own Ni can dish out, without a complaint. Big, brash, and bold – and unapologetic about it.

The Ti IEM utilizes pure titanium foil for the diaphragm material. Titanium is widely used in aerospace and high-performance applications because of its unique mix of extreme strength and stability with moderate weight, giving it one of the best stiffness-to-weight ratio of all structural metals.

All our IEMs feature Eastman Tritan™ bodies for high strength and zero resonance, custom front-and-rear tuned volumes, Metal-Injected-Molded grade 304 stainless steel logo caps, butyl rubber strain reliefs, chemically etched grade 316 stainless steel grilles, and N48H grade magnets.  All held together in perfect precision with advance cyanoacrylate adhesives and sealed with polyvinyl acetates.

Every IEM set comes with a full set of accessories.  We manufacture our own earbuds from medical grade silicones and urethanes, and we include small, medium, and large sizes of single flange, dual flange and foam units.  We stamp our own screw-top carry tin sized to fit inside the coin pocket of a pair of your favorite jeans.  And you’ll get adapters that let you use your IEMs with any equipment, whether at home (the 1/4″ gold plated adapter jack) or on the go (the lightweight, gold plated airplane adapter).

Still not sure that this IEM is for you?  Then use our amazing Select-A-Tron to guide your IEM choice!

Specifications

Performance
Frequency Response 16 Hz to 30 kHz
Impedance 32 Ohms nominal
Sensitivity 96 dB SPL at 1mW in ear
Power Handling 200 mW continuous
Peak SPL 117.5 dB
THD Less than 1.5% THD at 1mW
Physical Properties
Cable Length 1.5 m
Mass 2.8 / 9.3 g (IEM/Set)
Operational Temperature -20 to +50° C
Operational Humidity 0-95% Relative Humidity
NRR 31.3 dB (foam eartrip)
Overall Length 21 mm
Body Diameter 12 mm
Nozzle Diameter 6 mm
Material Properties
Melting Point 1941 Kelvin
Speed of Sound 5090 meters per second
Young’s Modulus 116 Gigapascals
Brinell Hardness 2770 Megapascals
kddev

Additional information

Weight 1 kg

Description

Ti (Titanium) is our “just plain fun” IEM.  In your face. Kick in the pants. Boogie down or bang the head. Ti does it all. This isn’t your 3 piece jazz ensemble IEM. This is a full-on, blast your face rock concert. It’s a thunderous EDM club. It’s reggae all day long.

Titanium is widely used in aerospace and high-performance applications because of its unique mix of extreme strength and stability with moderate weight, giving it one of the best stiffness-to-weight ratio of all structural metals.

Still not sure that this IEM is for you?  Then use our amazing Select-A-Tron to guide your IEM choice!

Nerd Layer

What’s New With the Ti?
We’ve done a few great changes to Ti – and the whole line – to improve performance and user experience.  This starts with a new material for the entire enclosure.  We worked for 3 years with Eastman Chemicals, one of the largest plastics companies in the world, to research, develop, and quantify new polymers for acoustic applications.

Our research led us to a specific blend of their Tritan™ copolymer.  This material proved to be not just rigid, but acoustically dead with lower energy storage and transmission than the polycarbonate we were using.  Stray resonance and noise is lowered even more.

We also refined the external and internal geometry to make it more anti-resonant, so clarity is increased alongside the improvements of the materials used.  The result is the most stable, lowest resonant IEM enclosure ever made.  All with the lowest weight enclosure possible.

I See a Detachable Cable?  What’s That About?
We have also developed our own 2.5mm jack: the IDEEL connector.  This connector is the world’s smallest 2.5mm jack, measuring just 3.6mm across, and a tiny 9.5mm mounting depth. This jack allows us to use the very robust 2.5mm TS plug in our tiny IEMs.  No more delicate MMCX or difficult 2 pin plastic connectors needed.

Mechanical Elements

Transducer Diaphragm: Pure Titanium foil
Transducer Surround: PEEK polymer
Transducer Frame: 316 Stainless Steel
Transducer Magnet: N48H Grade Neodymium
Enclosure Body: Tritan™ copolyester
Protective Grille: 316 Stainless Steel
Bonding Compound: Cyanoacrylate Adhesive
Sealant Compound: Polyvinyl Acetate
Mounting Tips: Medical Grade Silicone and Urethanes
Connector: IDEEL 2.5mm TS compatible connector (tip hot, sleeve ground)

All components are Finite Element Analyzed for stress, strain, and durability.

Performance Specifications

Frequency Response: 16 Hz to 30 kHz

Impedance: 32 Ohms nominal

Sensitivity: 96 dB SPL at 1mW in ear

Power Handling: 200 mW continuous

Peak SPL: 119 dB

THD: Less than 1.5% THD at 1mW

Included Components

Cable Length: 1.2 m

Mass: 2.8 / 16.7 g (each IEM/Set)

Operational Temperature: -20 to +50° C

Operational Humidity: 0-95% Relative Humidity

NRR: 31.3 dB (foam eartrip)

Overall Length: 21 mm

Body Diameter: 12 mm

Nozzle Diameter: 6 mm

Buy Titanium V3 For only $129.00 USD

Save $20 on each of these great accessories for your IEM!
This item: Titanium V3
IEM
Clear
$129.00 USD
$129.00 USD
1 × Rhodium DAC
Original price was: $49.00.Current price is: $39.00.
1 × Neon Dual Source BT Receiver
Original price was: $89.00.Current price is: $59.00.
1 × Silver IDEEL Connector Cable
Original price was: $49.00.Current price is: $29.00.
1 × Neutron MMCX to 2.5 TS Adapter
Original price was: $10.00.Current price is: $0.00.
